Duty: 2.4 MM Btu/hr Heat Absorption
Fluid: 281M Marine Hot Oil
Flow Rate: 100 gpm (Inlet and Outlet)
Inlet Temperature: 180.2 Deg F
Outlet Temperature: 300 Deg F
Fuel Type: Propane
Calculated Efficiency (LHV): 86%
Design Pressure: 150 psig
Design Fluid Temperature: 300 Deg F
Max Design Metal Temp: 550°F (Internal)
Hydrostatic Test Pressure: 195 PSIG
More Information Available Upon Request
