CNC Horizontal Machining Center
| X | 157" | 3,987.8 mm |
| Y | 90" | 2,286 mm |
| Z | 51" | 1,295.4 mm |
Request a Quote
Add to Cart
Pallet Size: 86.61" x 70.87"
X-Axis Travel: 157.4"
Y-Axis Travel: 90.5"
Z-Axis Travel: 51.2"
W-Axis Travel: 25.6"
Tool Diameter: 4.92"/9.45"
Tool Magazine Capacity: 40 ATC
Spindle Diameter: 5.1"
Spindle Speed: 4,000 RPM
Spindle Taper: CAT 50
Spindle Motor: 60 HP
Control: Fanuc 161M
Pallet Indexing: Full 4th Axis
Chip Removal: Chip Conveyor
Max Tool Length: 23.62"
Max Tool Weight: 66 Lbs
Machine Weight: 81400 Lbs
