CNC Horizontal Machining Center
| X | 25.2" | 640.08 mm |
| Y | 24" | 609.6 mm |
| Z | 26.8" | 680.72 mm |
| RPM | 15,000 RPM | 15,000 RPM |
| # ATC | 60 | 60 |
| Taper | 40 | 40 |
| # Axis | 4 | 4 |
Request a Quote
Add to Cart
Pallet Size (Millimeters): 400
Pallet Size: 15.7" x 15.7"
X-Axis Travel: 25.2"
Y-Axis Travel: 25"
Z-Axis Travel: 26.8"
Tool Magazine Capacity: 240 ATC
Spindle Speed: 15,000 RPM
Spindle Taper: CAT 40
Control: Fanuc 31ib
Pallet Indexing: Full 4th Axis
Chip Removal: Chip Conveyor
Pallet Surface to Spindle Center: 2.0-26.0 (50-660) in (mm)
Pallet Center to Spindle Nose: 3.9-30.7 (100-780) in (mm)
Pallet Load Capacity: 1100 (500) lbs (kg)
Max. Workpiece Size: ø 29.5 (750) for 2/6APC / ø 25.6 (650) for 8APC in (mm)
Pallet Change Time: 7.6 sec
X/Y/Z Axis Rapid Traverse: 3149 IPM
Cutting Feed (X/Y/Z): 1181 (30) in/min (m/min)
Additional Custom Common Variable: Automatic Tool Breakage Detection
Chipblaster J30 HP Coolant Thru Spindle (1000PSI): LNS Microfine Chip Conveyor
OMP-400 Renishaw Probe: Part Program to 8mb
8 Pallet Pool
