USED 2019 DMG MORI NZX-2000/800STY
Overview
Description
CNC Lathe
Specifications
| # Axis | 11 | 11 |
|---|---|---|
| Swing | 31.5" | 800.1 mm |
| Machining Length | 31.8" | 807.72 mm |
| Chuck Size | 10" | 254 mm |
| Bar Capacity | 2.5" | 63.5 mm |
| Power | 33 hp | 24.6 kW |
| Max RPM | 5,000 RPM | 5,000 RPM |
| Turning Dia | 11.8" | 299.72 mm |
| Tailstock | No | No |
Request a Quote
Add to Cart
Chuck Size: 8"
Bar Capacity: 2.5"
Swing: 31.5"
Turning Diameter: 12.5"
Spindle Speed: 5,000 RPM
Control: CELOS (F31iB)
Distance Between Centers: 44"
Turret: 16 Station
Live Tooling: C-Axis Live Tooling, Y-Axis
Sub-Spindle: 6,000 RPM
Chip Removal: Side Exit Scraper Type Chip Conveyor
Approx. Machine Dimensions: 199.3" x 111.6" x 91.3"
Approx. Machine Weight: 22,000 Lbs
(2) Micro Centric MBS 200 Collet Chucks: (3) Turrets with Y-Axis
(5) External M-Codes: 21.5" Color Ergoline Touch TFT
3D Coordinate Conversion: 4-Color Signal Light
Air Blow for Tool Tip (T1/T2/T3): Air Purge (Left and Right Spindle)
Auto Tool Presetter (Left and Right Spindle): C-Axis High-Precision Indexing
Chip Blaster/Chip Chiller High Pressure Coolant System: Chuck Top Coolant
Tool Retract and Recover: X-Axis Direct Scale Feedback (X1/X2/X3)
X-Axis Direction JIS / ISO: Built-In Work Light
Parts Catcher: Automatic Door
Coolant Gun: Ethernet Capability
Hobbing Function
