| size | 41"x 20" x 20" | 41"x 20" x 20" |
| X Travel | 41.3" | 1,049 mm |
| Y Travel | 20" | 508 mm |
| Z Travel | 20" | 508 mm |
| Power | 25 hp | 18.6 kW |
| RPM | 12,000 RPM | 12,000 RPM |
| # ATC | 38 | 38 |
| Table-W | 21.6" | 548.64 mm |
| Table-L | 51.1" | 1,297.9 mm |
Mazak Model Nexus VCN510C-II 2 Pallet CNC Vertical Machining Center
Table Working Surface: 21.65" X 51.18" (2)
Load Capacity: 2646 LBS
X-Axis Travel: 41"
Y-Axis Travel: 20"
Z-Axis Travel: 20"
Spindle Face to Surface: 26"
Column Face to Spindle Center: 22.6"
Taper 40
Spindle Speed: 12000 RPM
Tool Changer Positions: 48
Rapid Feeds XYX: 1417 IPM
Main Motor Drive: 25 HP
Floor Plan without P/C: 158" x 114" (includes C/C)
Floor Plan with P/C: 288" x 114" (includes C/C)
