| size | 23.2" x 20.2" | 23.2" x 20.2" |
| X | 13.8" | 350.52 mm |
| Y | 9.8" | 248.92 mm |
| Z | 8.6" | 218.44 mm |
| Auto Threading (Yes/No) | Yes | Yes |
| Dimensions | 77.7" x 81.6" x 80.71" | 77.7" x 81.6" x 80.71" |
| Weight | 4,400 lbs | 4,400 lbs |
Machining Stroke (X x Y x Z) - 13.8" x 9.8" x 8.6"
Table Size - 23.2" x 20.2"
Maximum Workpiece Size - 31.5" x 23.6" x 8.5"
Maximum Workpiece Weight - 1,105 lbs
Machining Stroke (U x V): ±1.25" x ±1.25"
Taper Capacity: +-30 deg max / +-15deg @ 4"
Wire Diameter Range Possible - 0.006"~0.012"
Wire Guides Included - .010"
Min Hole Diameter for Autothread - .020"
Max Wire Spool Size - 22 lbs
Filter Tank Capacity - 116 gal
