USED AUTOQUIP SERIES 35

Autoquip Series 35 Electric Scissor Lift Table2,500 lb Capacity | 36" Travel | 1.5 HP Motor | Model 36S25The Autoquip 36S25 is the industry standard for durability and reliability in vertical material handling. This Series 35 model offers a robust 2,500 lb lifting capacity with a compact footprint, making it ideal for ergonomic workstations and pallet positioning. Featuring solid steel-reinforced legs and chrome-plated joints with 100,000 PSI pins, this lift is built for high-cycle industrial use. The onboard 1.5 HP internal power unit and prewired controls allow for easy "plug and play" installation.Tech SpecsModel: 36S25 (Series 35)Capacity: 2,500 lbs (1,134 kg)Travel Distance: 36 inchesLowered Height: 6.5 inchesRaised Height: 42.5 inchesStandard Platform: 24" x 48" (Max oversized: 48" x 72")Motor: 1.5 HP Super Torque TENV MotorPower: 230V or 460V, 3-Phase (Standard Internal Power Unit)Lifting Speed: 12 seconds (Up) / 6 seconds (Down)Safety Features: Hydraulic velocity fuses, 3:1 structural safety factor, and maintenance safety locksKey Selling PointsProven Durability: Chrome-plated, high-strength pins and 1/4" thick steel-reinforced platforms minimize deck deflection and extend service life.Ultra-Low Profile: A 6.5" lowered height allows for easy loading and unloading of pallets and heavy machinery components.Integrated Safety: Standard hydraulic velocity fuses prevent uncontrolled descent in the event of a hose rupture, ensuring operator safety.Maintenance Friendly: Features a semi-transparent oil reservoir for instant fluid level checks and lubricated-for-life bearings that require no greasing.

Modified item: No
* Capacity: 2,500 lbs (1,134 kg)
* Lowered Height: 6.5 inches
* Travel Distance: 36 inches
* Raised Height: 42.5 inches
