BOX WAY CONSTRUCTION ON ALL 3 AXES FOR MAXIMUM RIGIDITY
RIGID 6,000 RPM SPINDLE WITH GEARBOX FOR HEAVY DUTY CUTTING
MAX TABLE LOAD CAPACITY OF 4,409 LBS. FOR MACHINING HEAVY PARTS
32 TOOL MAGAZINE DUAL ARM ATC
FULLY ENCLOSED SPLASHGUARD
| X | 63" | 1,600.2 mm |
| Y | 33.46" | 849.88 mm |
| Z | 29.53" | 750.06 mm |
| Power | 2,025 hp | 1,510 kW |
| RPM | 6,000 RPM | 6,000 RPM |
| # ATC | 32 | 32 |
| Taper | CT-50 | CT-50 |
| Table-W | 70.86" | 1,799.8 mm |
| Table-L | 33.46" | 849.88 mm |
| Control | CNC (FANUC 0I) | CNC (FANUC 0I) |
| Dimensions | 193" x 148" x 133" | 193" x 148" x 133" |
| Weight | 30,865 lbs | 30,865 lbs |
