| Chuck Size | 15.35" | 389.89 mm |
| Power | 20 hp | 14.9 kW |
| Max RPM | 3,500 RPM | 3,500 RPM |
| Tailstock | Yes | Yes |
| Dimensions | 98.42" x 70.6" x 75.78" | 98.42" x 70.6" x 75.78" |
| Weight | 8818.49 lbs | 8818.49 lbs |
Turning length - 22"
Turning - 9.45
Above the bed - 1.8"
Above transversing slide - 17.7"
Length between centers - 17.7"
Type of CNC FANUC 0TT
X-axis - 7.87"
Z-axis - 17.7"
Max workpiece weight kg
Spindle taper ASA A2-6”
Spindle bore - 3"
Number of tools on turret 12
Number of rotating tools 12
Turning speed - 3500 rpm
