USED 2025 PROWINCH Bridge & Overhead Cranes

The Prowinch 5-Ton Indoor Overhead Crane is engineered for reliable heavy-duty lifting and long-span coverage in warehouses, fabrication shops, and industrial plants. Built with a 40 ft span and 25 ft lifting height, this crane system provides powerful material handling capacity with precision control and safety.

Featuring a Prowinch hoist and SEW drive motors, the crane delivers smooth, variable speed operation with Schneider VFD drives on all motions. Operators benefit from dual control options – pendant and wireless remote (Telecontrol/Joy) – for flexibility and safety.

With a 310 ft long travel runway, dual drive motors, and integrated safety systems including anti-collision sensors, load indication display, limit switches, beacon, and siren, this crane ensures consistent uptime and reduced risk during operation.

Rated M5 service class, the crane is suitable for high-duty cycle applications. The Prowinch 5-ton overhead crane offers a turnkey solution to increase productivity and handling efficiency.

Capacity: 5 Ton (1 Hoist)
Span: 40 ft
Lifting Height: 25 ft
Long Travel Distance: 310 ft
Column Spacing: 20 + 27 + 27 … 20 ft
Ambient Temperature Range: –20°C to +40°C
Service Class (ISO/CMMA): M5 : C
Voltage: 460V, 60 Hz, 3-phase
Drive Control: VFD on all motions (Schneider)
Hoist Make: Prowinch
Motor Brand: SEW
Control Options: Pendant + Radio Remote (Telecontrol/Joy)
Cross Travel Speed: 16 – 65 ft/min (0.37 kW drive)
Long Travel Speed: 32 ft/min (0.37 kW × 2 motors)
Hoist Speed: 0.8 – 4.3 m/min
Rail Size: 50 × 30 mm
Protection: IP65
Safety Features:
