Built to unleash more output every shift, Baileigh Gear Head Engine Lathes combine brute turning power with disciplined control. These are true shop workhorses, engineered for smooth, authoritative cuts, faster stops, and cleaner containment that keep operators locked in and production moving.
| Lathe Type | Geared Head | Geared Head |
| Swing Over Bed | 14" | 355.6 mm |
| Distance Between Centers | 40" | 1,016 mm |
| Spindle Bore | 2" | 50.8 mm |
| Spindle Nose | D1-5 | D1-5 |
| Number Of Spindle Speeds | 8-Steps | 8-Steps |
| Range Of Speeds | 90-1800 RPM | 90-1800 RPM |
| Number of Inch Threads | 40 | 40 |
| Motor | 3 hp | 2.2 kW |
| Phase | 1 | 1 |
| Voltage | 230v | 230v |
| Amps | 13.3 | 13.3 |
| Dimensions | 3.6 x 31.3 x 50 in. | 3.6 x 31.3 x 50 in. |
| Weight | 1,808 lbs. | 1,808 lbs. |
Specifications are subject to change without notice.
NOTE: Data is provided by the manufacturer.
WARRANTY: 1YEAR – Parts
Machine Photo May Include Optional Equipment
Product image is only a representation, actual product appearance may differ slightly
