New | in-Stock

NEW 2025 Femco BMC-110R2

Ohio, United States
1,923Listings|28Followers
Overview
Horizontal Table Type Boring Mills

#50 Taper, 35 HP Geared Head Spindle,
Full B Axis Rotary Table, linear scales on X, Y & Z, chip conveyor,
Fanuc CNC control. Delivery, Installation and Training.......

Specs
Spindle Size
4.33"
109.98 mm
X-Horiz Tvl of Table
78.74"
2,000 mm
Y-Vert Tvl of Head
70.87"
1,800.1 mm
Power
35 hp
26.1 kW
RPM
2,500 RPM
2,500 RPM
Table-W
56.69"
1,439.9 mm
Table-L
62.99"
1,599.9 mm
Spindle Tvl.
19.6"
497.84 mm
Dimensions
78.74” x 70.87” x 64.96”
78.74” x 70.87” x 64.96”

Spindle Speed 2,500 RPM (CT-50 Taper – 30/35 HP)
Through Spindle Coolant
60 Tool ATC
Full B-Axis Rotary Table (13,889 Lbs. Load Capacity)
Travel W-Axis: 19.69”
