| Spindle Size | 5.1" | 129.54 mm |
| X Axis - Table Travel | 118.1" | 2,999.7 mm |
| Y Axis - Vertical Head Travel | 78.7" | 1,999 mm |
| Z Axis - Spindle Travel | 63" | 1,600.2 mm |
| W Axis - Quill Travel | 27.6" | 701.04 mm |
| B Axis - Table Rotation | 0.001 | 0.001 |
| Table Dimensions | 70.9" x 63" | 70.9" x 63" |
| Power | 35 hp | 26.1 kW |
| RPM | 2,500 RPM | 2,500 RPM |
| Max Table Load | 22,000 lb | 9,979 kg |
| Tool Changer Capacity | 60 | 60 |
| Dimensions | 309" x 285" x 173" | 309" x 285" x 173" |
| Weight | 72,600 Lbs | 72,600 Lbs |
Fanuc Series 31i Model B5 CNC Control
Full 4th-Axis Contouring
Coolant thru spindle
Renishaw Part Probe
Chip Conveyor
Splash guard
