4 axis, 10k RPM
| X Axis Travel | 40" | 1,016 mm |
| Y Axis Travel | 32" | 812.8 mm |
| Z Axis Travel | 35" | 889 mm |
| B Axis | .001 deg | .001 deg |
| Spindle Motor | 35 kW | 46.9 hp |
| Spindle Speed | 10,000 RPM | 10,000 RPM |
| ATC Capacity | 60 | 60 |
| Spindle Taper | CAT50 | CAT50 |
| Pallet Size | 24.8" x 31.5" | 24.8" x 31.5" |
| Number of Pallets | 2 | 2 |
| Table Load Capacity | 2,640" | 67,056 mm |
| Dimensions | 248" x 1237" x 144" | 248" x 1237" x 144" |
| Weight | 39,600 Lbs. | 39,600 Lbs. |
Fanuc 18iMB CNC Control
Tool Touch Setter
Bi-Directional Tool Selection
Coolant Through Spindle
Chip Auger System
Chip Conveyor
15-Second Pallet Change Time
Electrics-230 Volt 3/60
