| X-Axis | 51.2" | 1,300.5 mm |
| Y-Axis | 39.3" | 998.22 mm |
| Z-Axis | 23.6" | 599.44 mm |
| A-axis | 60 degree | 60 degree |
| C-axis | 120 degree | 120 degree |
| # Axis | 5 | 5 |
| Spindle Motor | 30 hp | 22.4 kW |
| Spindle Speed | 20,000 RPM | 20,000 RPM |
| ATC Capacity | 40 | 40 |
| Taper | HSK - A63 | HSK - A63 |
| Table Size | 51.18" x 39.37" | 51.18" x 39.37" |
| Table Load Capacity | 5512 lb | |
| Cut Hours | 538 hr. | 538 hr. |
| Control | CNC (Pro 6 Control) | CNC (Pro 6 Control) |
- Makino PRO6 Fanuc Based Control
- 40 Station ATC
- 20,000 RPM HSK63A Spindle (newly replaced)
- Swivel Head +/- 30 Degrees
- Through Spindle Coolant - 210 PSI
- Laser Tool Measuring
- Spindle Probe
- Core Cooled Ballscrews
- Overhead Shower Coolant
- Oil Skimmer
- Scale Feeback on Ballscrews
- Spindle Chiller
- Lift Up Chip Conveyor
- Fanuc 1GB Data Center
- Makino SGI.5 3D processing technology
- Various Fanuc 5 Axis Control Options
** MFG Date 2018 but machine installed in 2019 **
