| X-Axis | 7.9" | 200.66 mm |
| Y-Axis | 7.9" | 200.66 mm |
| Z-Axis | 11" | 279.4 mm |
| Table Dia. | 7.87" | 199.9 mm |
| A-axis | +130° –15° | +130° –15° |
| C-axis | 360° | 360° |
| # Axis | 5 | 5 |
| Spindle Motor | 20 hp | 14.9 kW |
| Spindle Speed | 42,000 RPM | 42,000 RPM |
| ATC Capacity | 24 | 24 |
| Taper | HSK40 | HSK40 |
| Table Size | 14.56″ x 12.59″ | 14.56″ x 12.59″ |
| Table Load Capacity | 220 lb | |
| Dimensions | 80″ x 65″ x 93″ | 80″ x 65″ x 93″ |
| Weight | 8,250 Lbs | 8,250 Lbs |
Siemens 840D CNC Control
Through Spindle Coolant
High Speed Machining
Programmable Swiveling Trunnion Table
MPG Handwheel Control
Rigid Tapping
Spindle Orientation
Telescopic Way Covers
Chiller Unit
Coolant Recycler Unit
Mist Collector
Coolant System
Books & Manuals
