| X Axis Travel | 78.74" | 2,000 mm |
| Y Axis Travel | 51.18" | 1,300 mm |
| Z Axis Travel | 51.18" | 1,300 mm |
| A Axis | 60° +/- 30° | 60° +/- 30° |
| B Axis | 360° | 360° |
| C Axis | 370° +/- 185° | 370° +/- 185° |
| Spindle Speed | 12,000 RPM | 12,000 RPM |
| ATC Capacity | 120 | 120 |
| Spindle Taper | HSK-A100 | HSK-A100 |
| Table Size | 59” x 47” | 59” x 47” |
| Max Load | 22,000 lb | 9,979 kg |
Makino Professional 5 CNC Control
1200 psi High Pressure Through Spindle Coolant
Filtration
Chip Conveyor
Renishaw Probing System
460v/3ph/60hz
