USED YALE KAL1-15RT23S1

Yale KAL Series | 1 Ton Air Chain Hoist & Power TrolleyOVERVIEWThe Yale KAL1-15RT23S1 is a high-performance pneumatic lifting system engineered for the most demanding industrial environments. This 1 Ton unit is equipped with a motorized air trolley, allowing for seamless, spark-free horizontal travel along a monorail or bridge crane. Designed to operate at 90 PSI, this hoist offers variable speed control and an unlimited duty cycle, ensuring it stays cool and efficient during continuous, high-volume production.TECHNICAL SPECIFICATIONSManufacturer: Yale Hoists (CMCO)Model: KAL1-15RT23S1Capacity: 1 Ton (2,000 lbs)Lifting Speed: 13 FPM (at 90 PSI)Air Consumption: ~71 CFMOperating Pressure: 90 PSITrolley Type: Motorized Pneumatic Power TrolleyControl: Pendant Throttle (Variable Speed)Classification: Spark-Resistant / High Duty CycleKEY FEATURESUNLIMITED DUTY CYCLE: Unlike electric hoists that require "rest" periods to cool down, the air-cooled rotary vane motor in the KAL series can run 100% of the time without risk of burnout.VARIABLE SPEED CONTROL: The pendant throttle allows for incredibly precise load spotting. The operator can "feather" the controls to move the load at a literal crawl or at full speed (13 FPM).POWER TROLLEY CONVENIENCE: The motorized RT trolley provides effortless movement along the beam, significantly increasing safety and reducing operator fatigue when moving 2,000 lb loads.SAFETY-FIRST DESIGN: Features a Weston-type mechanical load brake and a heavy-duty internal muffler to keep noise levels down in the shop. The pneumatic power source makes it ideal for hazardous or wet locations where electricity is a danger.RUGGED CONSTRUCTION: Built with a lightweight yet tough die-cast aluminum frame and heat-treated planetary gearing for maximum durability and quiet operation.

Capacity: 2000 lbs
Operating Pressure: 90 PSI
Approx Lift Speed: 13 FPM
CFM: 71
* Capacity: 1 Ton (2,000 lbs)
* Air Consumption: ~71 CFM
* Operating Pressure: 90 PSI
* Trolley Type: Motorized Pneumatic Power Trolley
* Control: Pendant Throttle (Variable Speed)
