All essential castings are made of high grade Meehanite® cast iron that is stress relieved through annealing to eliminate internal stress High precision cartridge type spindle equipped with 4 pieces of class 7 angular contact ball bearings, suitable for heavy duty grinding Separate hydraulic system prevents vibration and reduces heat transference Saddle travels on Turcite-B coated and hand scraped double V guideways.
PDF
http://hillaryinc.net/chevalierpdf/chevalier-FSG-3A818.pdf
| Table-L | 18" | 457.2 mm |
| Table-W | 6" | 152.4 mm |
| Grinding Wheel Dia. | 8" | 203.2 mm |
| Grinding Wheel Width | 0.5" | 12.7 mm |
| Horizontal/Vertical | Horizontal | Horizontal |
| Operation | Semi-Automatic | Semi-Automatic |
| Power | 2 hp | 1.5 kW |
