FANUC OiMF 3 axis CNC control with 8.4” LCD Mono Screen; 4 fully automatic grinding cycles: rapid approach, rough grinding, fine grinding, and wheel dressing with automatic compensation; X axis has double V guideways coated with Turcite-B; Y axis has hardened and ground box guideways; Z axis has THK linear guideways
All 3 axes are AC servo motor driven which is suitable for creep-feed grinding. Spindle supported by six (6) ABEC class 7 (P4) super precision angular contact ball bearings.
PDF
http://hillaryinc.net/chevalierpdf/Chevalier%20FSG-H,B818%20C1224CNC%20(201804).pdf
| Control | CNC (Fanuc) | CNC (Fanuc) |
| Table-L | 24" | 609.6 mm |
| Table-W | 12" | 304.8 mm |
| Grinding Wheel Dia. | 4" | 101.6 mm |
| Grinding Wheel Width | 14" | 355.6 mm |
| Horizontal/Vertical | Horizontal | Horizontal |
| Operation | CNC | CNC |
| Power | 30 hp | 22.4 kW |
