Generous capacities and excellent performance over its entire range of motion
| Control | CNC (ProtoTRAK RLX CNC) | CNC (ProtoTRAK RLX CNC) |
| Swing | 16" | 406.4 mm |
| Distance Between Centers | 30" | 762 mm |
| Bar Capacity | 1.57" | 39.878 mm |
| Max RPM | 4,000 RPM | 4,000 RPM |
| Power | 7.5 hp | 5.6 kW |
| Tailstock | Yes | Yes |
ProtoTRAK RLX CNC integrated into the machine at the factory
Manual or CNC operation
Electronic handwheels and jogstick
Brushless servo motors
Inverter-duty spindle drive
Programmable spindle speeds
Constant Surface Speed (CSS) Programming
Inch Per Revolution (IPR) Programming
Optional TRAKing® for manual control of CNC programs
Optional turret for automatic tool changes
