Fanuc 31iMB control, 50hp, 15k spindle, CAT 40, 2x 19.7" pallets, rotary pallet changer, 60 ATC, full 4th axis, chip conveyor, air curtain, coolant chiller, coolant through spindle,
| X Axis Travel | 31.5" | 800.1 mm |
| Y Axis Travel | 31.5" | 800.1 mm |
| Z Axis Travel | 31.5" | 800.1 mm |
| Spindle Motor | 50 hp | 37.3 kW |
| Spindle Speed | 15,000 RPM | 15,000 RPM |
| ATC Capacity | 60 | 60 |
| Spindle Taper | CAT40 | CAT40 |
| Pallet Size | 19.7" x 19.7" | 19.7" x 19.7" |
| Number of Pallets | 2 | 2 |
| Control | CNC | CNC |
| Dimensions | 194" x 111" | 194" x 111" |
Fanuc 31iMB Control
Full 4th B-Axis
Mosnic High-Volume Rolling Filter Chip Conveyor w/ Magnetic Separator
Through Spindle Coolant 256 PSI at 15 GPM [seals to 1,000PSI for future upgrade]
Spindle Air Curtain
Spindle Oil Chiller
Spindle Flood, Bed Flush & Ceiling Shower Coolant
Refrigerated & Temperature Controlled Spindle, Ballscrews & Servo Motor Mounts
Total Enclosed Splashguard w/ Manual Operated Doors
CE Spec
Inch/Metric Switchable Capability
Helical Interpolation & Coordinate Rotation
2MB Total Program Memory
Automatic Corner Override
Tool Offset Memory Type-C & 200 Tool Offsets
Custom Macro B
