Stainless Hopper Small Parts Feeder Floorbin Elevator 8"x 48"H Conveyor 220V 1PH
USD $1,519.95
Overview
Specifications
In Good Used Condition, Removed from a Working Environment.
Stainless hopper, aluminum conveyor frame with adjustable steel mounting brackets.
220V 1PH direct drive gearmotor. 75:1 reducer ratio.
Bin size 23"L x 20-1/2"W x 18" Deep.
Conveyor Length: 43"
Belt Width: 8"
Cleat height: 1" spaced 1-1/4" apart.
60° Conveyor Incline with the hopper at level.
48" Overall height. Drive is mounted on bottom end.
11-3/8" Conveyor frame width.
