1k cutting hours, Heidenhain iTNC 530 CNC Control, 3+2, Renishaw TS-27R Probe, Touch Probe Infrared OMP40, Hem Rotary Tilting Table, Hem Linear Glass Scales 500U, Conveyor Lift Up Chip
| X-Axis | 19.69" | 500.13 mm |
| Y-Axis | 17.71" | 449.83 mm |
| Z-Axis | 15.75" | 400.05 mm |
| A-axis | +65° –120° | +65° –120° |
| C-axis | 360° | 360° |
| # Axis | 5 | 5 |
| Spindle Motor | 25 hp | 18.6 kW |
| Spindle Speed | 12,000 RPM | 12,000 RPM |
| ATC Capacity | 30 | 30 |
| Taper | ISO40 | ISO40 |
| Table Size | 19.69" x 19.69" | 19.69" x 19.69" |
| Table Load Capacity | 661 lb | |
| Dimensions | 105″ x 128″ x 132″ | 105″ x 128″ x 132″ |
| Weight | 13,294 Lbs | 13,294 Lbs |
1k Cutting Hours
Heidenhain iTNC 530 CNC Control
5-Axis Machining
Renishaw TS-27R Probe
Touch Probe Infrared OMP40
Assortment of Tooling
Tool Magazine DT40/BT40 & ISO4
TC Arm Holder For ISO 40
Kinematicsopt
(2) Compressed Air Through Spindle
Compressed Ball 30 with Base
Hem Rotary Tilting Table
Hem Linear Glass Scales 500U
Conveyor Lift Up Chip
Movable Hand Wheel
Manual Touch Cycles Heidenhain
Manual Pilot Smart NC Heidenhain
Manual DIN/ISO Programming Heidenhain
Air Required: 100 psi, 4 scfm
Power: Kw / 400v / 3-Phase
