For sale: 2007 HAAS VF-2SS Vertical Machining Center. Features: X 30", Y 16", Z 20" travel, 30 HP, 12,000 RPM, 24-tool ATC, CT/BT 40 taper. Table size: 14" x 36". A reliable addition to your workshop.
| X | 30" | 762 mm |
| Y | 16" | 406.4 mm |
| Z | 20" | 508 mm |
| Power | 30 hp | 22.4 kW |
| RPM | 12,000 RPM | 12,000 RPM |
| # ATC | 24 | 24 |
| Taper | CT or BT 40 | CT or BT 40 |
| Table-W | 14" | 355.6 mm |
| Table-L | 36" | 914.4 mm |
Specs
Spindle Speed: 12,000 RPM
Machine Hours: 18,613
Control: Haas CNC
Power: 208 / 230 Volt
Phase: 3 Phase
Frequency: 50 / 60 Hz
Full Load Amps: 80 Amps
Largest Load: 70 Amps
Enclosure Rating: NEMA Type 1 (Indoor Use)
Short Circuit Interrupting Capacity: 10,000 Amps
Date of Manufacture: 11/2007
Haas VF-2SS SuperSpeed VMC
Chip Auger
Programmable Coolant Nozzle
Coordinate Rotation & Scaling
Intuitive Programming
4AXBL
Inbound Freight
