Southbend 4601DD-3CR 60" 4 Burner Gas Range W/ Charbroiler & (2) Standard Ovens, Liquid Propane
Overview
Description
This range from Southbend features four burners, a 36-inch charbroiler, and two standard ovens. The 4601DD3CRLP runs on propane, and has a manual gas shutoff on the front of the unit for added safety. The range top is easy to clean, due to removable grates and drip trays, and a porcelain enamel finish and coved corners make the oven interior easy to keep clean as well.
Specifications
Manufacturer
Southbend
Additional Info
Contact Customer Service for altitudes above 2,000 feet
Application
Restaurant
Base
Standard Oven
BTU / Burner
24000
Burner Configuration
Standard
Burner Style
Grates
Burner Type(s)
Open
Charbroiler Location
Right
Charbroiler Width (in)
36
Controls
Manual
Depth (in)
34
Gas Inlet Size
0.75
Gas Type
LP
Heat
Gas
Height (in)
59.5
Installation Type
Freestanding
Max Temp
550
Number of Burners
4
Number of Ovens
Double
Open Burner BTU (ea)
24000
Product
Gas Ranges
Product Type
Cooking Equipment
Rack Positions per Standard Oven
2
Racks per Standard Oven
1
Range Configuration
Burners/Charbroiler
Rating
Better
Series
Ultimate
Special Features
Spark Ignition
Standard Oven BTU/hr
45000
Standard Oven Dimensions
26"W x 26.5"D x 14"H
Total BTU
318000
Vent
Backriser w/ hi-shelf
Warranty
1-year Limited Parts & Labor
Width (in)
60
Weight
1075.00
Specifications
Manufacturer: Southbend
Additional Info: Contact Customer Service for altitudes above 2,000 feet
Application: Restaurant
Base: Standard Oven
BTU / Burner: 24000
Burner Configuration: Standard
Burner Style: Grates
Burner Type(s): Open
Charbroiler Location: Right
Charbroiler Width (in): 36
Controls: Manual
Depth (in): 34
Gas Inlet Size: 0.75
Gas Type: LP
Heat: Gas
Height (in): 59.5
Installation Type: Freestanding
Max Temp: 550
Number of Burners: 4
Number of Ovens: Double
Open Burner BTU (ea): 24000
Product: Gas Ranges
Product Type: Cooking Equipment
Rack Positions per Standard Oven: 2
Racks per Standard Oven: 1
Range Configuration: Burners/Charbroiler
Rating: Better
Series: Ultimate
Special Features: Spark Ignition
Standard Oven BTU/hr: 45000
Standard Oven Dimensions: 26"W x 26.5"D x 14"H
Total BTU: 318000
Vent: Backriser w/ hi-shelf
Warranty: 1-year Limited Parts & Labor
Width (in): 60
Weight: 1075.00
