Used 90 Ton Heim Model 9GT OBI/Gap Frame Press. Features include 95-ton capacity, 36"x26" bed, 3" stroke, and 14" shut height. Equipped with a 10 HP motor, air clutch/brake, and palm buttons.
| Ton | 95 T | |
| Bed L-R | 36 in | |
| Bed F-B | 26 in | |
| Stroke | 3 in | |
| Adjustment | 4 in | |
| Shut Height | 14 in | |
| Speed (max) | 50 strokes/min. | 50 strokes/min. |
| OBI Single Double | Single | Single |
| Dimensions | 50" LR 107" FB X 117" TALL | 50" LR 107" FB X 117" TALL |
95 TON CAPACITY
3" STROKE
4" RAM ADJUSTMENT
14" SHUT HEIGHT
50 SPM
36" LR X 26" FB BED
18.25" X 13" RAM
31" THROAT
AIR CLUTCH
AIR BRAKE
AIR COUNTERBALANCE
PALM BUTTONS
20" BETWEEEN HOUSINGS
10 HP 230/460/60/3
