NEW HYDMECH CSNC-110XL

HYDMECH (NEW) MODEL CSNC-110XL HIGH SPEED
CNC CARBIDE CIRCULAR SAW

CAPACITY
- 1" - 4.33" ROUND AT 90 DEGREES
- 1"-3.15" SQUARE AT 90 DEGREES
360MM X 2.25MM KERF CARBIDE/CERMET TIPPED BLADE SIZE
10' - 20' BAR STOCK LENGTH
30 DEGREE SLANT TYPE CUTTING AXIS
ZERO OR PROGRAMMABLE FROM 0.4" TO 3.9" TRIM CUT
39" MULTI-INDEX STANDARD SINGLE STROKE
50-170 MPM BLADE SPEED
0.4" MIN CUT OFF LENGTH
3.94"/100 MM + CUT LENGTH +CUTTER THICKNESS
REMNANT LENGTH
20 HP BLADE DRIVE
3 HP/5 HP WITH NON-ROUND LOADER HYDRAULIC DRIVE
240, 480, 575 VOLTS

STANDARD FEATURES
- MITSUBISHI PLC CONTROLLER ALLOWS FOR 200
PROGRAMS TO BE SAVED
- JOB MONITORING WITH CYCLE TIME, JOB DURATION,
PARTS COUNT AND AMP LOAD SETTING TO PROTECT THE
SAW BLADE
- MATERIAL LIBRARY WITH US STEEL GRADES MENU WITH
ABILITY TO ADD CUSTOM MATERIAL GRADES
- BAR FEED FEATURES A ROLLER BED WITH A MATERIAL
GRIPPER FEED CARRIAGE INDEXING VIA BALL SCREW
AND AC SERVO DRIVE
- 7.87" PER SECOND SHUTTLE SPEED
- HEAVY DUTY SAW HEAD IS DRIVEN BY BALL SCREW
AND AC SERVO DRIVE WITH A PATENT PENDING
COUNTERBALANCE FEATURE
- MIST EXHAUST SYSTEM
- AIR MOISTURE SEPARATOR
- UNIVERSAL BAR LOADER FOR ROUND AND
SQUARE MATERIAL WITH HYDRAULIC INCLINE PITCH
ADJUSTMENT AND SAFETY GUARD SHEETS PROVIDES
INCLINED STORAGE WIDTH OF 42" FOR ROUNDS
- 10,361 LBS CAPACITY
- PLC CONTROLLED AUTOMATIC OIL LUBRICATION
OF ALL MOVING PARTS
- OUTPUT SORTING ENSURES TRIM CUTS AND
REMNANT PIECES ARE SORTED AUTOMATICALLY
FROM GOOD PARTS
- VARIABLE VISE PRESSURE CONTROL WITH DIAL
GAUGE - TWO STATIONS WITH HYDRAULIC
HORIZONTAL AND VERTICAL CLAMPING
- COOLING NOZZLE
- BLADE LUBRICATION FEATURES TRIPLE JET SYSTEM
TO LUBRICATE BLADE
- COOLANT LEVEL GETS LOW, THE MACHINE WILL
ALARM TO ALERT THE OPERATOR
- HYDRAULIC ROTATING WIRED CHIP BRUSH ROTATES
IN BOTH DIRECTIONS FOR PROPER CHIP REMOVAL
- STATUS LIGHT INDICATING TOWER
- CHIP AUGER
- AIR COOLED ELECTRIC MAGNETIC HEAD BREAK REMOVES
ALL BACKLASH
- BUILT IN HYDRAULIC TANK AND POWER PACK
- TOOL STEEL HARDENED PRECISION BLADE GUIDES
- POWER TRANSFORMER
- FOUR BLADE STARTER PACKAGE
- 360/460MM X 2.25MM BODY X /4050 MM BORE
BLADE SPECS
- 4/15/80 MM PIN HOLES
- 4/12/90 MM BOLT HOLES

OPTIONS AVAILABLE - PRICE ON REQUEST
- STRAP STYLE BUNDLER LOAD - MAX WEIGHT 4 TONS
- CHAIN CHIP CONVEYOR
- LONG CUT OUTFEED MOTORIZED SLIDING TABLE - 1000MM TRAVEL
- LONG CUT OUTFEED MOTORIZED SLIDING TABLE - 2000MM TRAVEL
- LONG CUT OUTFEED MOTORIZED SLIDING TABLE - 3000 MM TRAVEL
- PLC PROGRAM MODIFICATION
- MAINTENANCE KIT - 4 SAW GUIDE PLATES, 2 METERING CARTRIDGE
LUBRICATION, 25 WIRE BRUSHES, SSR RELAY, NORMAL RELAY,
5 GLASS FUSES, PROXIMITY SENSOR, PHOTO SENSOR, AND MIST
PRE-COLLECTOR FILTERS
Power: 240, 480, 575 (3-Phase)
