Control: Fanucsystem R-J3iC
Capacity: 6Kg (13.22 lbs)
Supplementary Arm Payload Axis 3: 12Kg (26.45 lbs)
Repeatability: ±0.08mm (±0.003")
Horizontal Reach: 951mm (37.44")
Robot Motion Speed:
1-Axis 200 °/s
2-Axis 200 °/s
3-Axis 260 °/s
4-Axis 400 °/s
5-Axis 400 °/s
6-Axis 720 °/s
Robot Motion Range:
1-Axis ±170°
2-Axis +125°
3-Axis +155°
4-Axis ±190°
5-Axis ±140°
6-Axis ±360°
Work Cage
Misc Workholding Equipment
