Table Size: 23.6" X 12.6"
Table Load (Max): 440 LBS
X Axis Travel (Table): 15.8"
Y Axis Travel (Saddle): 9.8"
Spindle Travel (Manual Quill): 4"
Spindle Travel (Reciprocation Quill): 3.5"
Spindle Speeds: 9,000 - 45,000 RPM
Grinding Wheel, Coarse Adjustment: 2.36"
Grinding Wheel, Fine Adjustment: .16"
Grinding Wheel Graduations: .0001"
Grinding Wheel Capacities (Diameter): .02"-11.8"
Machine Dimensions: 61"W X 67"L X 91"H
Machine Weight: 5,100 LBS
Manual Table Feed System (X & Y Axis)
Digital Readout Display
(+/- .00004") Positioning Accuracy
(0-3 Degree) Tapered Grinding
