Swing Over Table, Maximum: 9-27/32"
Distance Between Centers: 23-5/8"
Grinding Wheel, Standard Dia.: 16"
Grinding Wheel, Standard Width: 2"
Grinding Wheel, Hole Dia.: 5"
Workhead Spindle Speeds (Infinite): 10 to 400 RPM
Grinding Hed Speeds (4): 1500 - 3600 RPM
Longitudinal Table Feeds (Hydraulic): .06 to 18 FPM
Automatic Infeed on Table Reversal: .00005" - .0012"
Swivel of Wheelhead: 270 Degrees
Swivel of Workhead: 360 Degrees
Table Swivel: 11 Degrees
Approximate Machine Dimensions: 102" x 64" x 66"H
Approximate Machine Weight: 6,100 lbs
Marposs E5 Guaging Control
Automatic Hydraulic Infeed
Plunge Feed and Tarry
Hydraulic Table Traverse
Rapid Wheelhead Advance and Retract
Single Lever Control
Infinitely Varible Table Traverse
