Round Tube Capacity: 3-1/2
Square Tube Capacity: 3-1/8 x 3-1/8
Round Solid Capacity: 2
Square Solid Capacity: 2 x 2
Maximum Blade Side Capacity: 12-1/2
Spindle Speed (var.): 18 88 rpm
Maximum Vise Opening: 7
Minimum Cut Length: 1/8
Max. Cut Length: 30, 60, 90
Max. Saw Blade Diameter: 12-1/2
Motor: 5 hp, 3/60/230v
Floor Space (machine only): 100 x 44 x 64H
Weight (approx): 1,770 lbs
Automatic Operation
10 Supply Track
Chip Conveyor
Coolant System
