X Axis Travel: 17.72"
Y Axis Travel: 12.60"
Z Axis Travel: 6.89"
U Axis Travel: +/- 1.97"
V Axis Travel: +/- 1.97"
Workpiece Dimensions: 43.31" x 29.92"
Max. workpiece height: 7.87"
Adjustable wire speed: from 2-15 m/min
Adjustable wire tension: from 3,5 to 20N
Adjustable taper angle: from 0-30 degrees
Work tank dimensions: 16.14" x 47.05" x 31.5"
Capacity: 380 litres
Tank (Reservoir): 34.25" x 29.53" x 83.07"
Capacity: 560 litres
Settling tank dimensions: 19.69" x 61.02" x 19.69"
Capacity: 350 litres
Machine Dimensions: 95" x 82.7" x 95"
Charmilles CNC Control
Filtering system: Settling tank + 4 cartridges
