Control: MSX-850 III
Max Swing Over Bed: 29.72"
Max Turning Diameter: 14"
Max Machining Length: 20"
Bar Capacity: 2.5"
Spindle Bore: 2.9"
Spindle Nose: A2-6
Spindle Speed: 50 - 5,000 RPM
Spindle Motor: 20 HP
Milling Speed: 6,000 RPM
Milling Motor: 7.5 HP
Turret Positions: 12 Stations
Machine Dimensions: 107" x 76" x 85"H
Machine Weight: 12,500 LBS
Live Tooling
Parts Catcher
Turbo Systems Chip Conveyor
LNS Quick 6 Bar Loader
Chip Blaster HP Coolant
