Control: MAZATROL EIA
Max Diameter Bar Capacity: 1.26"
Max Swing Over Bed / Carriage: 18.5" / 9.5"
Max Turning Diameter: 3.7"
Max Machining Length: 2.36"
X-Axis Travel: 11.8"
Z-Axis Travel: 9.45"
Spindle Motor: 7.5 / 5 HP
Spindle Speed: 35 - 7000 RPM
Spindle Bore: 1.73"
Spindle Nose: A2-6
Number of Tools on Gang: 6
Machine Dimensions (L x W x H): 96" x 70" x 62"
Machine Weight: 9000 lbs.
Chip Conveyor
GL-6 Autoloader
