Max Swing: 22.64"
Swing Over Cross Slide: 18.5"
Distance Between Centers: 60.0"
Max Turning Diameter: 22.64"
Max Machining Length: 60.0"
Min Spindle Index: .001 Degree
Main Spindle Speed: 35-3,000 RPM
Milling Spindle Speed: 3,000 RPM
Main Spindle Motor: 30 HP
Milling Spindle Speed: 3 HP
Milling Spindle Taper: CAT 40/KM
Tailstock Center: MT# 5
Machine Weight: 19,580 lbs
Mazak T-Plus Control
12" Kitagawa B12 Chuck
Tool Eye
Chip Conveyor
40 ATC Tool Magazine
