Control: Fanuc Oi-TB
Chuck Size: 12"
Max Diameter Bar Capacity: 3"
Max Swing Over Bed: 22.8"
Swing Over Carriage: 17.7"
Max Machining Diameter: 17.7"
Distance Between Centers: 28"
Spindle Motor: 25 HP
Spindle Speed: 3,500 RPM
Spindle Bore: 3.42"
Spindle Nose: A2-8
Number of Turret Tools: 12
Live Milling Speed: 3,000 RPM
Live Milling Motor: 5 HP
Tailstock Taper: MT #5
Machine Dimensions: (L x W x H) 177" x 83" x 89"
Machine Weight: 15,400 LBS
Full C-Axis
Barfeed Interface
Auto Parts Catcher
Programmable Tailstock Body & Quill
Three Color Tower Light
Chip Conveyor (Side Exit)
3 Jaw Chuck
Assorted Live and Static Tooling
Two Gear Range Headstock
Box Way Construction
