Control: Fanuc 0iTC
Max Swing Over Bed: 18"
Turning Diameter: 11"
Turning Length: 16"
Spindle Nose: A2-6
Spindle Bore: 2.05"
Spindle Speed: 5,000 RPM
Spindle Motor: 15 HP
Number of Turret Stations: 12
Machine Dimensions: 78"L x 65"W x 72"H
Machine Weight: 6,000 LBS
Chip Conveyor
VDI 30 Turret
8" 3-jaw Chuck
