Control: Fanuc 21T
Swing Over Bed: 21"
Max Turning Diameter: 8.25"
Max Turning Length: 14"
Spindle Nose: A2-5
Spindle Speeds: 50 - 5,000 RPM
Spindle Motor: 10 HP
Max Bar Capacity: 1.625"
Number of Turret Stations: 12
Tailstock Quill Taper: MT 3
Tailstock Quill Stroke: 3.93"
Machine Dimensions: 93"L x 68"W x 67"H
Machine Weight: 7,000 LBS
Parts Catcher
