Control: Fanuc 31iTD
Swing Over Bed: 30.7
Swing Over Carriage: 24.8"
Max Turn Diameter (main spindle): 14.8"
Max Turn Length: 29.92"
Distance Between Spindles: 43.46"
Main Spindle Nose: A2-8
Main Spinde Speed: 6,000 RPM
Main Spindle Motor: 30 HP
Main Spindle Bore: 3.38"
Number of Turret Positions: 12
Live Tool Spindle Speed: 5,000 RPM
Live Tool Motor: 7.5 HP
Y Axis Travel: 4.13"
B Axis Travel: 32.6"
Machine Dimensions: 153"L x 74"W x 85"H
Machine Weight: 14,300 LBS
B Axis (Sub Spindle)
C Axis (Live Tooling)
Y Axis
