Control: Fanuc 18
Max Swing Over Bed: 21.65"
Max Turning Diameter: 11.4"
Max Machining Length: 19.37"
Cross Travel (X-Axis): 8.07"
Longitudinal Travel (Z-Axis): 22.83"
Standard Chuck Size: 8"
Bar Capacity: 2.56"
Spindle Bore: 2.99"
Spindle Nose: A2-6
Spindle Speed Range: 45-4500 RPM
Spindle Horsepower: 20 HP
Sub-Spindle Nose: A2-5
Sub-Spindle Speed Range: 60-6000 RPM
Sub-Spindle Horse Power: 7.5 HP
Turret Tool Positions: 12
Milling Spindle Speed Range: 60-6000 RPM
Milling Spindle Horse Power: 5 HP
Machine Dimensions: 170"L x 74"W x 73"H
Machine Weight: 11,000 LBS
Live Tooling
Tool Probe
Bar Feeder
8 Samchully HH-208 Chuck
2 Live Tools (1 Radial, 1 Axial)
Parts catcher
Chip Conveyor
Barfeed Interface
All Manuals
