Maximum Machining Diameter: 1.65"
Maximum Machining Length: 3.15"
Backworking-Max. Chuck Diameter: 1.69"
Backworking-Max. Work Length: 3.15"
Spindle Speeds: 6,000 RPM
Spindle Bore: 1.82"
Spindle Motor: 15 HP
Backworking-Spindle Speeds: 6,000 RPM
Rotary Tool Motor: 1.3 HP
Number of Tools: 12 / 24 Tools
Turning Tool Size: 0.625"
Machine Dimensions: 90" x 66.6"
Machine Weight: 5,620 lbs
Chip Conveyor
Cincom System M16 CNC Control
Iemca VIP 80 Bar Feeder
