USED 2009 MATSUURA MAXIA
Specs
Control: GTECH 30i Fanuc
X-Axis Travel: 29.82"
Y-Axis Travel: 33.26"
Z-Axis Travel: 24.01"
A-Axis: +120 Degrees
B-Axis: -120 Degrees
C-Axis: 360 Degrees
Tables Size: 19.68" x 19.68"
Tables Load (max): 880 LBS
Spindle Speed: 12,000 RPM
Spindle Taper: BT-40
Spindle Motor: 30 HP
Tool Changer Capacity: 120 ATC
Tool Change Time: 1.1 Seconds
Rapid Traverse(X,Y,Z): 1969 IPM
Cutting Feeds: 1969 IPM
Machine Dimensions: 132"W x 246"L x 125"H
Machine Weight: 33,000 LBS
Equipped With
Data Server
Full 4th Axis(350,000 Degree) on B-Axis
Coolant Thru Spindle(1,000 PSI) w/Master Pump Unit
Tilting Trunion Table
2-Pallets (Dual Axis Rotary Tables)
Tool Chnager Expandable to 240 ATC
Turbo Chip Conveyor
