USED 1997 CINCINNATI U5
Specs
Control: ACRAMATIC 950
Table Working Surface: 66.9" x 137.8"
Table Load Capacity: 20,000 LBS
Distance between Columns: 95.4"
Clearance Under Rail: 75.5"
Longitudinal Travel (X-Axis): 157.5"
Cross Travel (Y-Axis): 146.2" (100" Working Travel)
Vertical Travel (Z-Axis): 39.4"
Rapid Traverse Rate (X ): 787 IPM
Rapid Traverse Rate (Y&Z-Axis): 787 IPM
Tool Storage Capacity: 60 atc
Spindle Horsepower Cont Rating: 30 HP
Spindle Speed Range: 40-6000 RPM
Spindle Taper: #50 CAT
Electrics: 460/3/60
Equipped With
Full 3-D Contouring Control
90 Degree Head Attachment
Scales
Renishaw Probe Sensing Units
Chip Conveyor
Coolant System
