Pallet Size: 24.8" x 24.8"
X-Axis Travel: 32"
Y-Axis Travel: 31.5"
Z-Axis Travel: 31.5"
Spindle Nose: CAT 40
Spindle Speed: 10,000 RPM
Spindle Motor: 30 MIN/ CONT 40 HP
Tool Magazine Capacity: 40 Position ATC
Max. Tool Diameter/ Length: 9.65" 15.7"
Max. Tool Weight: 77 lbs
Rapid Traverse: 1,771 IPM
Cutting Feed Rates: 787 IPM
Machine Weight: 36,800 lbs
Table Load Capacity: 2,640 lbs
Table Indexing: 1 Degree Index
Electrics: 220/ 200 V, 3 PH, 50/ 60 HZ
FANUC 10M CNC
(2) 24.8" x 24.8" Pallets
Coolant Thru Spindle
Chip Conveyor
40 Tool ATC & Renishaw Probe
Coordinate System Rotation
Rigid Tapping
Tool Length & Broken Tool Detection
99 Tool Length Offsets
Helical Interpolation
Macro B 100 Variables
