FEATURES
Used for cutting processes of aluminum, vinyl and wooden profiles.
Hydro-Pneumatic cutting
Servo controlled rotation axis
Secure cutting by the cover equipped with a safety sensor
Automatic positioning at all degrees between 30° and 90° with servo motion system
Industrial PC with Windows based touchscreen and easy to use practical interface
Remote Access
Data transfer over remote network connection, Ethernet and USB
Batch processing and precision cutting
Ability to perform cutting automatically from the list or manually
Process programming and large memory
Double hand control application
Adjustable saw blade travel speed
Ability to control saw blade travel distance
Automatic horizontal clamps
Automatic size calculation for mold cutting
Resume cutting feature (emergency stops, blackouts, etc.) provides cutting advice by making a full scan in cutting list and detecting uncut pieces.
Ability to send bar code information of different profile batches by profile list input without using a cutting optimization program and ability to choose profile from the list in batch cutting
Standard Equipment
22" saw blade
Cooling system
Digital conveyor
Optional Equipment
Barcode printer
Dust vacuuming system
Profile height measurement
Digital adjustment of saw blade travel distance
