NEW TOYODA FH5000S-I

Designed to achieve remarkable speed and production reliability, JTEKT’s FH5000 Series meets the growing demand for high metal removal rates, short cycle times and superior surface finishes. It features standard 60-tool ATC capacity, along with a 15,000 RPM, 50 HP (37 kW), 303 Nm (223 ft-lbs.) high acceleration spindle. Equipped with a direct drive B-axis table featuring an index time (90°) of 0.7 seconds - the FH5000’s spindle design, preload system and high torque features allow manufacturers to take advantage of more aggressive, high-volume machining in a compact footprint.
