NEW TOYODA LA-350 L16
Overview
Description
The LA model is designed with a high performance spindle, modulized structure with optional C axis and rigid boxway design, all in a compact footprint.
• 2 axes + C axis
• Gear box spindle
• Box guideway
LA-350 L8
Long bed turning center with 800 mm max. turning length
33.4" (850 mm) Z Travel
LA-350 L16
Long bed turning center with 1,600 mm max. turning length
65" (1,650 mm) Z Travel
LA-350 L22
Long bed turning center with 2,240 mm max. turning length
90.1" (2,290 mm) Z Travel
Specifications
| Swing | 30.7" | 779.78 mm |
|---|---|---|
| Machining Length | 63" | 1,600.2 mm |
| # Axis | 3 | 3 |
| Chuck Size | 12" | 304.8 mm |
| Bar Capacity | 4.6" | 116.84 mm |
| Power | 30 hp | 22.4 kW |
| Max RPM | 2,500 RPM | 2,500 RPM |
| Turning Dia | 21.6" | 548.64 mm |
| Tailstock | Yes | Yes |
