Fanuc 0i-MC
40"X,
21"Z, 19.7" x 44" Table, CAT-40 Taper, 10,000 RPM, 24 ATC, 15 Hp,
Chip Conveyor, Chiller, New 2010, VIDEO
AVAILABLE.
Table working surface……………………..………. 19.7" x 44"
X-axis travel……………………………………………… 40.2"
Y-axis travel……………………………………………… 20.5"
Z-axis travel………………………………………………. 21.3"
Distance spindle nose to table (min/max)……………...
4.7"/26"
Distance spindle center to column…………………….….. 22.8"
Spindle taper…………………………………………... CAT-40
Spindle speed (max)……………………………..… 10,000 rpm
Cutting feed rates………………………………. 0.04 – 394 ipm
Rapid traverse rate……………………………...……... 787 ipm
Max. tool weight…………………………………...…... 17.6 lb.
Tool change time (next tool)……………………………... 6 sec.
Spindle motor……………………………………………. 15 Hp
Dimensions (approx.)………………….. 85"W x 83"D x
119"H
Weight (approx.)…………………………………….. 11,660 lb.
Fanuc 0i-MC CNC control with remote MPG & RS232
24-Station side-mount automatic tool changer
Rigid tapping
Chip conveyor
Spindle oil chiller
