Coil Weight: 50000 pounds
Width: 70 inches
Max Coil Weight: 50,000lbs
Drum Diameter: 20” and 24”
70" Drum Face
67" Gripper Slot
49" to Top of Mandrel
24:1 Main Gear Box Ratio
Strip Clamp: Hydraulic
Push Off: Hydraulic
Overarm Separator: Pneumatic Operation
53" Length
Gear Box: 2 Speed
Motor: 100HP, D.C. 500V, 650-1950 RPM
Speed: 200 and 400 FPM (60-121 MPM)
Line Direction Right to Left or Left to Right
